RD-1390M
Summary
Processing materials widely, cutting edge smooth, burr free, free of polishing, processing speed, high precision, waste less, high efficiencyDouble head laser cutting machine can be selected, so that the work efficiency increases exponentially
Suitable for mass production of large and medium enterprises, and also meet the production needs of small enterprises and individual processing
New and unique structural design, support high-speed cutting, engraving, to meet all kinds of control requirements from low-end to high-end
Using high-performance laser engraving and cutting control platform DSP control system
Using a unique intelligent prediction algorithm and improved control algorithm to ensure the processing, smooth and efficient
Operation speed, laser energy real-time adjustable, greatly facilitate the operation of the customer
Cutting energy automatic compensation function, the cutting effect has been greatly improved
Attribute
Type: Metal and non-metal laser cutting machineModel: RD-1390M
laser tube power: 150w-260w
The alias: Metal and non-metal laser cutting machine
Specifications (mm): 150w-260w
Information
Processing area: 1300*900mm
Laser tube power: 180W
Engraving speed: 0-64000mm/mim
Maximum engraving depth: 8mm
Minimum formed text: Chinese characters 2 * 2mm, letter 1 * 1mm
Resolution: 4500dpi
Power supply: AC220V + 10%, 50HZ
Positioning accuracy: < 0.01mm
Power: less than 1250W
Operating temperature: 0C~45C
Working humidity: 5%~95% (without condensate)
Support graphics formats: BMP, HPGL (PLT), JPEG, GIF, TIFF, PCS, TGA, CDR, DWG, DXF.
Overall weight: 450KG
Size: 1900 * 1500 * 1200mm
